Ebyte ODM E32-433T33D long-distance lora spread spectrum 433nhz UART wireless serial port lora module

Large Image : Ebyte ODM E32-433T33D long-distance lora spread spectrum 433nhz UART wireless serial port lora module

Product Details:

Place of Origin:	China
Brand Name:	HUARAY
Certification:	FCC,CE,RoHS
Model Number:	E32-433T33D-V8.1

Payment & Shipping Terms:

Minimum Order Quantity:	2/pcs
Price:	Negotiable
Packaging Details:	Inner Staticproof Bag, External Cardboard Box
Delivery Time:	1~3 days
Payment Terms:	T/T Western Union, Moneygram, Paypal
Supply Ability:	500,000pcs/year

Contact Now

Detailed Product Description

Highlight:

RF Module

RF Transmitter Receiver Module

Wireless RF Transceiver

Wireless Data Module

Radio Modem

Ebyte ODM E32-433T33D long-distance lora spread spectrum 433nhz UART wireless serial port lora module

Key attributes

Model Number

E32-433T33D-V8.1

Brand Name

Ebyte

Chipset

Application

modules iot solutions

Type

LORA MODULE

Place of Origin

Sichuan, China

Supplier Type

OEM/ODM

Frequency

433MHz

Power

33dBm

Interface

UART

Size

37*60*7.6mm

Operation Range

12km

Transmit power

33dBm

Feature

LoRa

Name 1

lora module

Name 2

lora transmitter receiver module

Packaging and delivery

Selling Units

Single item

Single package size

5X3X2 cm

Single gross weight

0.005 kg

Specification

RF parameters	parameter value	Remark
Working frequency	410~441MHz	Factory default 433MHz
transmit power	33dBm	Factory default 30dBm (about 1W)
Receive sensitivity	-147dBm	Airspeed 0.3kbps
air speed	0.3k~19.2kbps	Factory default 2.4kbps
Measured distance	12000 meters	Clear and open environment, maximum power, antenna gain 2.5dBi, height 2.5m, airspeed 2.4kbps

Hardware parameters	parameter value	Remark
Size	37607.6mm	Tolerance ±0.1mm (excluding pin header height)
Antenna form	SMA-K
Communication Interface	UART serial port	The baud rate supports 1200~115200, the factory default is 9600
Packaging method	patch
Cache capacity	512 bytes	Internal automatic sub-packet 58 bytes transmission

Electrical parameters	Min	Typ	Max	Unit
voltage	3.3	5	5.5	V
communication level		3.3		V
Emission current	850	1000	1200	mA
receive current	11	13	15	mA
sleep current		2		μA
Operating temperature	-40	20	85	℃
Working humidity	10	60	90	%
