FSC-BT806B CSR8675 Master & Slave Tx Rx BT5.0 Ultra-low-power Dual-mode SPP BLE Serial SoC Bluetooth Audio Module

Large Image : FSC-BT806B CSR8675 Master & Slave Tx Rx BT5.0 Ultra-low-power Dual-mode SPP BLE Serial SoC Bluetooth Audio Module

Product Details:

Place of Origin:	China
Brand Name:	Huaray
Certification:	FCC, CE, RoHS, ISO9001
Model Number:	FSC-BT806B

Payment & Shipping Terms:

Minimum Order Quantity:	2pcs
Price:	Negotiable
Packaging Details:	Inner Staticproof Bag, External Cardboard Box
Delivery Time:	one or two working days
Payment Terms:	T/T, L/C, Western Union, Paypal, Moneygram
Supply Ability:	50,000pcs/year

Contact Now

Detailed Product Description

Key attributes

Model Number

FSC-BT806B

Chipset

CSR8675

Application

Bluetooth audio transmitting/receiving device

Place of Origin

Guangdong, China

Type

Bluetooth 5.0

Country of Origin

Shenzhen

Brand

Huaray

Dimensions (mm)

13 * 26.9 * 2.2; Pad Pitch 1.0

Frequency

2.402 ~ 2.480 GHz

Transmit Power

+10 dBm (Maximum)

Profiles

A2DP/AVRCP/HFP/HSP/HID/PBAP/SPP/BLE

Control Ianterfaces

UART, I²C, SPI, PIO, AIO, USB

Raw Data Rates (Air)

3 Mbps (Classic BT - BR/EDR)

Audio interfaces

I²S/PCM and SPDIF

Operating Temperature

-40°C to +85°C

Supply Voltage

VDD_IO: 1.7V ~ 3.6V ; VBAT_IN: 2.8V ~ 4.3V

Miscellaneous

Lead-free and RoHS compliant

Packaging and delivery

Selling Units

Single item

Single package size

12X10X3 cm

Single gross weight

0.150 kg

Contact Details

Oriental Huaray Group Limited

Contact Person: Mr. Jet Zhang

Tel: 18025358250

Fax: 86-755-23007123
