50ohm Low Loss RF Coaxial Cable RG174 with SMA MALE to SMA FEMALE Connector or Antenna

50ohm Low Loss RF Coaxial Cable RG174 with SMA MALE to SMA FEMALE Connector or Antenna
50ohm Low Loss RF Coaxial Cable RG174 with SMA MALE to SMA FEMALE Connector or Antenna

Large Image :  50ohm Low Loss RF Coaxial Cable RG174 with SMA MALE to SMA FEMALE Connector or Antenna

Product Details:
Place of Origin: China
Brand Name: Huaray
Certification: FCC, CE
Model Number: GPS Antenna
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Inner Staticproof Bag, External Cardboard Box
Delivery Time: In two or three days
Payment Terms: T/T, L/C, Western Union, MoneyGram, Paypal
Supply Ability: 10,000pcs per month
Contact Now
Detailed Product Description

2G 3G 2.4Ghz 5g 5.8g 4G LTE Antenna SMA patch antenna 5dbi with extension cable RG174 3 meters SMA Male

Key Specifications/Special Features:

Dielectric antenna:

Center frequency: 1575.42 ± 3MHz

VSWR (in BW): 1.5:1

Bandwidth: ±5MHz

Impedance: 50Ω

Polarization type: RHCP

LNA/filter:

LNA gain (without cable): 28 ± 2dB (typical)

Noise figure: 1.5dB

DC voltages: 2.2 to 5V

DC current: 5 to 15mA

Mechanical:

Dimensions: 48 x 38 x 14mm

Mounting: magnetic/adhesive

Housing: black

Packaging dimensions: 120 x 95 x 20mm

Optional cable: RG174, 3m or others

Optional connectors: SMA/MCX/SMB/BNC or others

Environmental:

Working temperatures: -40 to 85°C

Humidity: 55 to 75% RH

Waterproof grade: IP67
