Smart Home UK Standard Zigbee Light Switch Double Push Button Panel Automatic With Alexa Voice Control TUYA Smart Switch 240V

Large Image : Smart Home UK Standard Zigbee Light Switch Double Push Button Panel Automatic With Alexa Voice Control TUYA Smart Switch 240V

Product Details:

Place of Origin:	China
Brand Name:	HUARAY
Certification:	FCC,CE,RoHS
Model Number:	HR-2001

Payment & Shipping Terms:

Minimum Order Quantity:	2/pcs
Price:	Negotiable
Packaging Details:	Inner Staticproof Bag, External Cardboard Box
Delivery Time:	1~3 days
Payment Terms:	T/T, Western Union, Moneygram, Paypal
Supply Ability:	500,000pcs/year

Contact Now

Detailed Product Description

Highlight:

ZigBee Module

ZigBee Module CC2530

CC2591 ZigBee Module

Wireless RF Module

GSM/GPRS Module

2.4G ZigBee Modules

----- Smaller size, high anti- interference, automatic network

*Home appliances intelligent control

*Auto Meter Reading system

*Industry telemetry and automatic data collection system

*Wireless monitor, door’s security, personnel orientation

*Traffic and the control for street lamp

*Logistics, active RFID and wireless handheld terminal

*Temperature and humidity control system for hotel

PERFORMANCE
Power Output:	20dbm (Default)
RF Line-of-sight Range:	1000m(BER=10^-2)
RF Effective Rate:	250kbps
Interface baud rate:	2400～115200bps
Space Channel:	5MHz
Bandwidth:	2MHz
Receiver Sensitivity:	-105dBm
SYSTEM CHARACTERISTIC
Networking Topology:	IEEE 802.15.4 protocol, ZigBee ntomatic etwork, Transparent,formatted API and AT command
	Modbus transmission protocol (Optional ex-factory)
RF IC:	TI CC2530F256 ,256k Flash
	4 ways ADC, 4 ways IO port(customized )
COMPATIBILITY
HR-2000
POWER
Supply Voltage:	+3.0~3.6V
Transmit Current:	≤160mA
Receive Current:	≤32mA
Sleep current:	≤3µA(customized )
GENERAL
Communication Mode:	Half-duplex
Frequency Band:	2.4～2.5GHz
Modulation Mode	QPSK
Channel:	16 (Default)
Interface:	TTL/UART
PHYSICAL PROPERTIES
Size:	35.1mm×24.4mm×4mm (excluding antenna base and data pin)
Weight:	30g
Antenna Base:	50Ω, antenna
Operating Temperature:	Industrial:-40℃~+80℃
Frequency Stability:	±20ppm
CERTIFICATIONS
FCC,CE,RoHS	Meet
